Brand: TARGET Brakes
Part Number: TB-2424PDGN-04
Chamber Style: Diaphragm Piston
Distance Between Bolts: 120.7mm
Port Threads: M22 x 1.5 with Adapter M16*1.5
Stroke: 64/64mm
Pushrod Thread: Ball R8
Pushrod Length: 15mm
Bolt Threads: M16 x 1.5
Reference No. : RENAULT: 7420522028 VOLVO: 20522028 VOLVO: 2159622
Type: Disc G-24/24
Max Working Pressure: 1.03Mpa
Working Temperature: -40℃～+80℃
Life Time: Service chamber:above 1,000,000 times Parking chamber:above 200,000 times
Finish: E-coating/Zinc-plated/Aluminum sand-blasted
Weight（kg) : 8.6
Customized service: Laser logo-MOQ:100pcs Outer packaging customization：500pcs Pattern customization：500pcs
Adaptive Model: VOLVO, RENAULT
qwe: 123
Output Force: 8600N
Release Pressure: 0.51Mpa
